Nominal pressure (MPa)

Test pressure 1.0 1.6 2.5 4.0

Shell strength test 1.5 2.4 3.75 6.0

Sealing test (liquid) 1.1 1.76 2.75 4.4

Sealing test (gas) 0.5~0.8 MPa

Applicable medium water, steam, gas, dust, oil, etc.

Applicable temperature 200℃

Valve material Ductile iron, cast steel, stainless steel

FLS-wDTJ/02 series intelligent temperature control valve is suitable for industrial heat exchange, heating and refrigeration equipment and process flow, and also suitable for civil heating and air conditioning control.

The intelligent temperature control valve is composed of a temperature sensor, an intelligent actuator and a regulating ball valve. The temperature sensor can choose a variety of sensors according to different working conditions. The intelligent actuator has the function of position control and PID control. According to user needs, the position Type control, turn on or turn off at the high limit, turn off or turn on at the low limit: use the PID function to control the temperature to be stable near the set value. The positive action and reverse action setting functions meet the conversion of cold source regulation {seasonal change Functions} The intelligent actuator displays the temperature set value and current value, displays the valve opening, and provides a user-friendly operation interface and debugging menu.

The intelligent temperature regulating valve integrates sensors, valves, actuators, temperature controllers and power modules in an integrated design, which simplifies the workload of user selection.
